Drought’s No. 1 lesson: Modernize water management

Dry fields and bare trees looking west, near San Joaquin, Calif. Photo by Gregory U

Dry fields and bare trees looking west, near San Joaquin, Calif., on Feb. 5, 2014. Photo by Gregory Urquiaga/UC Davis

Jeff Mount, Ellen Hanak, Bruce Cain, Caitrin Chappelle, Richard Frank, Brian Gray, Richard Howitt, Katrina Jessoe, Jay Lund, Josué Medellín-Azuara, Peter Moyle, Leon Szeptycki and Buzz Thompson

This year’s drought is testing how well California manages water during severe dry periods.

As we head into spring and the major irrigation season, rainfall totals, snowpack, reservoir storage and groundwater levels are all low. Although most larger urban areas have relatively secure water supplies, some small, isolated communities can expect problems. And California will be dealing with significant, painful choices on agricultural land use and environmental flows.

Problems dealing with this drought – the worst in more than 30 years – point to opportunities for improving how we manage this recurring feature of our climate. Overall, California needs to modernize drought policies and management in at least four areas: statewide measurement systems, ecosystems, groundwater and pricing.

Tracking water supply and use: You can’t manage what you don’t measure

California’s urban water systems have become much better at planning for and handling droughts, thanks to local initiatives and prodding from the state to increase drought preparation. Unfortunately, the state’s own drought planning apparatus is showing weaknesses during this severe drought.

The State Water Resources Control Board has authority to administer and enforce water right priorities, investigate waste and unreasonable use, and balance water deliveries during drought emergencies. The California Department of Water Resources (DWR) develops information on current and expected flows.

During wet, average and even relatively dry periods, this system provides some stability to water management and allows water users to plan activities. However, during severe droughts, deficiencies in the transfer of information and supporting technology severely compromise the water board’s ability to monitor, enforce and allocate scarce supplies.

Legacy technology. Despite major advances in predictions of flow volume and timing, short-term drought flow forecasts and measurements are often lacking at locations and times needed for efficient drought-water allocations.

And in a hold-over from procedures established more than 70 years ago, DWR publishes only monthly updates of hydrologic conditions and water supply projections from February through May. Some flow records — such as those collected by hydropower utilities — are even embargoed, precluding state officials from real-time access to useful data. During severe droughts, water operations and protection of water right priorities need more thorough and frequent updates from all sources.

Who uses how much? The 2009 package of water legislation significantly advanced water rights enforcement and quantification with new reporting requirements for all surface-water users. However, California still has a long way to go to improve its recordkeeping and consolidate its water-use data sources. Water rights records and statements are likely to be of variable accuracy. And most critical to management during a drought, there is little or no information about which water users have access to groundwater – usually 30 percent to 40 percent of total supplies, and more during droughts.

irrigation

Source: California Department of Water Resources

Modern measurements – using satellite imagery, remote sensing, sensor networks and sophisticated computer models – makes it possible to estimate water use by crops, native vegetation and urban landscapes without requiring additional reporting by water users.

This cost-effective technology has been used in California in isolated cases, but the state lacks both infrastructure and the coordinated interagency efforts to get the best out of this information.

Idaho has a long-term program to account for water use and actively employ this technology to manage water, including in court cases involving water rights enforcement and consumptive use. Nevada and other western states also use this technology for water rights. This technology is inexpensive (just cents per acre in Idaho: Allen et al. 2005) and accurate (as shown in a recent study on the Delta: Medellín-Azuara and Howitt 2013).

Calling rights during drought emergencies. In many places worldwide with seniority-based water rights, senior water users must announce their water use during times of shortage so that water diversions can be scheduled to make the most use of available water. When senior water users have reserved rights that go unused in real time, this deprives other potential users of this water and reduces overall system reliability.

During drought emergencies, California should have a system requiring large senior water users to “call” their rights and quantities on the Web, so water use can be better scheduled and coordinated in water-short basins.

The lessons? California needs to modernize its water rights system – along with flow forecasting and reporting requirements for water use – to make the most water available to water users during a drought. And to avoid being caught unprepared for the next severe drought, the state should run detailed drought operation and curtailment exercises every two to five years. Such exercises would give water managers the opportunity to simulate real-time responses to drought emergencies and to identify information and coordination gaps that need to be filled before the next major drought.

Environment: plan, prepare and prioritize

One essential information gap is understanding options for managing environmental flows during severe droughts.

Source: California Department of Water Resources

Source: California Department of Water Resources

California’s native species have, through natural selection, adapted to the state’s variable climate. However, these species are now attempting to survive in novel ecosystems, with highly altered hydrology and habitat often dominated by non-native species (Moyle et al, 2011, 2013).

Failing to manage ecosystems well during a drought can lead to additional endangered species listings, more opportunities for invasive species to become established and long-term disruptions to water operations. For example, high levels of export pumping from the Delta during the 1987-1992 drought were followed by an influx of invasive species such as the overbite clam, and expansion of other species, such as Brazilian waterweed, which now plague system management (Winder et al. 2011).

A modern drought policy must include better preparations for environmental management.

During a declared drought emergency, the state water board often softens environmental standards to benefit human water users, typically with the concurrence of federal and state fish agencies. Regulators also may be forced to make difficult and complex tradeoffs about flow allocations when multiple threatened or endangered species rely on the same limited water supply.

These decisions inevitably involve considerable guesswork, because there has been little effort in advance of a drought emergency to evaluate the scientific basis for making these decisions. Legally, fish in regulated rivers should always have sufficient flows to maintain their populations, based on the Fish and Game Code and the Public Trust Doctrine (Bork et al., 2012). But these legal issues are often ignored, especially during drought.

In addition to helping manage these tradeoffs, planning ahead can also prompt policies that make ecosystems more drought-resilient.

Chinook salom guard nest in Big Spring Creek near Mount Shasta. Phot oby Carson Jeffres/UC Davis

Chinook salmon guard nest in Big Spring Creek near Mount Shasta. Photo by Carson Jeffres/UC Davis, October 2012

One concept with strong support in the conservation literature is to establish strongholds or refugia: specialized rivers and streams managed to maintain resilient native fish populations as a hedge against disturbances such as drought. Also, if environmental flows take a major hit during drought – as they are this year – then a funding mechanism should be in place to assist recovery of depleted species and damaged ecosystems, perhaps funded in part with sales of water from environmental curtailments.

Failure to adequately plan usually results in severe depletion of environmental water, which ultimately will result in creation of more endangered species, invasions of alien species and declines in fisheries. Recovering from these new problems will complicate water management long after the rains return.

Groundwater as drought storage: managing a not-so-rainy day fund

Substantial seasonal and drought water storage is essential for water management in California. Surface storage behind dams totals approximately 41 million acre-feet, or about two-thirds of the state’s annual net water use, including dedicated environmental flows (DWR, 2013). Groundwater storage capacity is at least several times larger, and groundwater is the major source of storage during droughts.

Yet a major limitation on groundwater as our principal hedge against drought is that we tend to mine it in normal and even wet years in some agricultural areas, decreasing our drought resiliency.

U.S. Geological Survey scientists say cracks and buckles along the Delta-Mendota Canal are likely caused by subsidence from groundwater overdraft. Photo by Amy Quinton, Capital Public Radio, November. 2013 by Amy Quinton, Capital Public Radio

U.S. Geological Survey scientists say cracks and buckles along the Delta-Mendota Canal are likely caused by subsidence from groundwater overdraft. Photo by Amy Quinton, Capital Public Radio, November, 2013

The cumulative historical overdraft statewide is several times the average annual natural flow from all California rivers, and the problem is especially evident in the Tulare Basin (Faunt et al. 2009). Groundwater overdraft entails many costs, including extensive dewatering of rivers and wetlands, damage to irrigation and flood infrastructure because of subsidence and making groundwater prohibitively expensive and less reliable during both wet and dry years (Faunt et al. 2009).

Groundwater basin management – through special management districts that oversee and charge for pumping or adjudicated basins that allocate pumping rights – is already common in the state’s urbanized areas, whose groundwater overdraft problems became acute in earlier decades. Such management enables coordinated use of surface and groundwater storage (often called conjunctive use), whereby groundwater basins serve primarily as drought storage.

Active groundwater storage is one reason why southern California urban communities are little affected by the current dry period. In contrast, the Central Valley has few conjunctive use programs, despite abundant potential. Agriculture’s pain during this drought would be significantly lower if these groundwater basins were operated sustainably.

Managing demand: paying for water

If urban areas are better prepared for this drought, it is also thanks to the ability of most local water utilities to raise water rates to pay for new investments in conservation, surface and groundwater storage, and non-traditional supplies like recycled wastewater and stormwater capture. However, not all is well on this front.

Drought pricing. The drought is likely to result in another round of financial problems and discord because of a lack of sound drought pricing and messaging.

Most water system costs are fixed; those for distribution pipes, treatment plants and labor don’t vary with the volume of water delivered. Unless most of the monthly bill is a flat fee (which dims price incentives to consumers to use water efficiently), revenues often cannot cover fixed costs during droughts, when extraordinary conservation reduces water sales and revenues. Utilities then must raise rates after the drought.

ucla

Water-saving micro-emitter sprinkler in UCLA’s botanical garden. Source: UCLA

This practice sends a mixed message to customers, who conserved water as requested and are then rewarded with higher rates.

Anticipating such problems with special drought pricing policies can rectify this situation. The utility establishes a drought rate schedule in advance, which allows it to announce and charge a higher per-gallon rate during droughts.

Drought pricing keeps the utility solvent while providing a special conservation price incentive to customers. Only a few communities now do this (Roseville and Los Angeles are examples).

Unfortunately, following the smaller drought of the late 2000s (when sales also fell because of the recession), many water utilities opted instead to put a higher share of their bills into fixed service charges, thereby dimming incentives to conserve (Hanak et al. 2014).

Understanding customer behavior. Our understanding of decision-making by residential water users is far from complete, making it difficult to choose the most effective conservation policies.

The introduction of real-time meters and collaborations between utilities and researchers can improve our knowledge about customer behavior.

As an example, recent work suggests that the deployment of WaterSmart, a service that provides social comparisons and water savings tips, led to a 5 percent reduction in water usage in pilot areas within the East Bay Municipal Utilities District (Mitchell and Chesnutt, 2013).

The pilot project points to the potential role of non-price policies to induce conservation. Additional utility-researcher collaborations, using detailed billing data on water usage, can help provide insights into the price responsiveness of residential customers and inform the design of rate structures.

Funding new infrastructure. Although urban agencies have been able to make drought resiliency investments, rising regulatory costs and decreasing reliability of water supplies from imported sources (especially the Delta) will drive up the cost of maintaining drought resiliency.

A $10.6 million modernization of Morris Dam in Los Angeles County allowed 1,500 additional acre-feet of water to be delivered annually down the San Gabriel River, to replenish aquifers. The project was paid for in part with funds from Proposition 50 (2002), which the sale of $3.4 billion in general obligation bonds  for a variety of projects. Photo by Chris Austin

A $10.6 million modernization of Morris Dam in Los Angeles County allowed 1,500 additional acre-feet of water to be delivered annually down the San Gabriel River, to replenish aquifers. Photo by Chris Austin

Constitutional restrictions imposed by Proposition 218 – a 1996 voter-approved initiative – may limit the ability of utilities to continue modernizing (Hanak et al. 2014). The measure requires that new fees be linked to specific services delivered to each property. Under narrow interpretations of this law, fees that do not directly reflect the costs of service to a property can be considered taxes, requiring approval by a two-thirds supermajority of voters.

Utilities have faced Prop. 218-related legal challenges to conservation-oriented rate structures like tiered pricing (which encourage conservation by charging a higher price per gallon for larger volumes of water use) and to the system-wide sharing of costs of adding new supplies like recycled wastewater (which improves overall supply reliability even though it usually can’t be delivered to all properties).

Modern, integrated water resource management recognizes the broad benefit associated with improving water systems, where it is difficult to precisely assign direct benefits to specific properties.

To avoid this problem, California’s courts should interpret Prop. 218 with an understanding of the realities and requirements of integrated water management. Constitutional reform of Prop. 218 to introduce more flexibility also may be needed so utilities can manage future droughts and provide reliable service to a growing population and economy.

Although droughts are economically, socially and environmentally disruptive, they also provide a stress test on California’s preparedness for an uncertain future. California has made significant progress in drought management in recent years, but mostly in the large metropolitan regions that have developed more diversified, integrated water sources, thanks to a ready source of local funding and forward-thinking leadership.

The current drought has revealed significant weaknesses in our current policies and practices:

  • A failure to modernize and coordinate water information at the state level
  • A tendency to set drought policy on supply and the environment during a severe drought rather than before it
  • A failure to develop emergency measures for the environment
  • An unwillingness to adequately prepare groundwater management and storage for droughts

Although this drought is significant, it is not unprecedented. This water year will be likely the worst third or fourth driest since we began keeping detailed records in 1895. In other words, it’s a “25- to 40-year” drought. We manage more systematically for rarer hazards, conducting annual dry runs for floods, earthquakes and fires that test our ability to respond.

It’s time to start doing the same for drought. Let’s call them “wet runs,” because we would do this before we’re in a drought, when water is more plentiful.

Many of the changes we suggest could be accomplished under existing law, with limited additional resources. The state already has authority to make improvements in measurement, forecasting and drought planning – including for use of environmental flows during droughts to protect fish.

Legislation may be needed to further improve surface water-use reporting (such as requiring large water users to report annually). Legislation will be needed to facilitate some other changes, such as to enable groundwater management agencies to charge pumping fees to improve basin management (something now only readily possible for a few specially mandated agencies.) The Legislature also can support better drought pricing by local agencies, by requiring utilities to consider their fiscal response to droughts in their urban water management plans.

California needs to modernize its preparations for drought. The time to start on modernization is not after the drought, when rains wash away the memory of it, but during the drought when political motivation and public attention are greatest.

Jeff Mount, Ellen Hanak and Caitrin Chappelle are with the Public Policy Institute of California. Richard Frank, Richard Howitt, Katrina Jessoe, Jay Lund, Josué Medellín-Azuara and Peter Moyle are with the UC Davis Center for Watershed Sciences. Brian Gray is with the UC Hastings College of the Law. Bruce Cain, Leon Szeptycki and Buzz Thompson are with Stanford University.

Further reading:

Raw data: http://cdec.water.ca.gov

Allen, RG, Tasumi, M. and Morse, A. 2005. Satellite-Based evaporation by METRIC and Landsat for Western States Water Management. U.S. Bureau of Reclamation Evapotranspiration Workshop. Forth Collins, Colo. Feb. 8-10, 2005

Baxter, R, and others. 2010. Interagency Ecological Program 2010 Pelagic Organism Decline Work Plan and Synthesis of Results: Interagency Ecological Program for the San Francisco Estuary

Börk, K.S. J. F. Krovoza, J. V. Katz, and P. B. Moyle. 2012. The rebirth of California Fish & Game Code 5937: water for fish. UC Davis Law Review 45: 809-913

California Department of Water Resources. 2013. Draft California Water Plan, Update 2013

Faunt, C.C., ed., 2009, Groundwater Availability of the Central Valley Aquifer, California: U.S. Geological Survey Professional Paper 1766, 225 p.

Hanak, H., B. Gray, J. Lund, D. Mitchell, C. Chappelle, A. Fahlund, K. Jessoe, J. Medellín-Azuara, D, Misczynski, J. Nachbaur, R. Suddeth. 2014. Paying for Water in California. San Francisco: Public Policy Institute of California

Medellin-Azuara, J., Howitt, R.E. (2013). Comparing Consumptive Agricultural Water Use in the Sacramento-San Joaquin Delta: A proof of concept using remote sensing. A report for the Delta Protection Commission. 27 pp.

Mitchell, D., T. Chestnutt, 2013. Evaluation of East Bay Municiupal Utility District’s Pilot of WaterSmart Home Water Reports. Technical report prepared for California Water Foundation and East Bay Metropolitan Utility District

Moyle, P.B., J. V. E. Katz and R. M. Quiñones. 2011. Rapid decline of California’s native inland fishes: a status assessment. Biological Conservation 144: 2414-2423

Moyle, P.B., J. D. Kiernan, P. K. Crain, and R. M. Quiñones. 2013. Climate change vulnerability of native and alien freshwater fishes of California: a systematic assessment approach. PLoS One. DOI: 10.1371/journal.pone.0063883. May 2013

Weiser, Matt (2014), “California drought puts spotlight on water theft,” The Sacramento Bee, Mar. 23, 2014

Winder, M., A.D. Jassby, and R. MacNally. 2011. Synergies between climate anomalies and hydrological modifications facilitate estuarine biotic invasions. Ecology Letters. doi: 10.1111/j.1461-0248.2011.01635.x
